Heavy Duty Steel Props
Heavy Duty Adjustable Steel Scaffolding Props Specifications
Product Type
Heavy-duty adjustable telescopic steel prop for scaffolding and formwork support
Material Grade
High-tensile structural steel, typically Q235 or Q355
Inner / Outer Tube Diameter (OD)
40/48 mm, 48/56 mm, or 48/60 mm
Tube Wall Thickness
1.8–4.0 mm, depending on tube size and prop model
Adjustable Height Range
1.8–3.2 m, 2.0–3.6 m, 2.2–4.0 m, or 3.0–5.0 m
Base Plate
120 × 120 mm or 150 × 150 mm square steel plate; 4–6 mm thick
Top Plate / Head Options
120 × 120 mm or 150 × 150 mm top plate; optional U-head or fork head
Surface Finish / Protection
Hot-dip galvanized, galvanized, powder coated, or painted
