Italian Type Frame Scaffolding
Italian Type Frame Scaffolding Specifications
Product Type / Frame Geometry
Italian type frame scaffolding, Portal (PE) or Bushed (B)
Material Grade
Structural steel, typically Q235 or Q355
Main Tube Outside Diameter (OD)
42.7 mm (1.68 in) or 48.3 mm (1.90 in)
Wall Thickness
2.0–3.2 mm
Standard Width
1,050 mm (3 ft 5 in)
Standard Height
2,000 mm (6 ft 7 in)
Span Length Options
1,800 mm (5 ft 11 in) or 2,500 mm (8 ft 2 in)
Surface Finish / Protection
Galvanized, powder coated, or painted
